SB – 17 Electric Paper Reel Stacker

For lifting of Plastics Rolls, Paper Reels, Cloth Rolls, etc.

• Ideal for handling anything which rolls and required to lift.
• Available capacity: From 500 kgs to 1500 Kgs.
• Lifting Height: From 600 mm to 3500 mm.
• Available options: Electric operated & manual & Battery operated.

Product Code		SB – 17	SB – 17	SB – 17	SB – 17
Rated Capacity	kg	500 / 1000 / 1500	1000 / 1500	1000	1000
Load Center	mm	600	600	600	600
Max. Fork Height	mm	1600	2500	3000	3500
Fork Length	mm	1150	1150	1150	1150
Fork Width	mm	600	600	600	600
Minimum height	mm	90	90	90	90
Overall Length	mm	1500	1500	1500	1500
Overall Height	mm	2050	1800	2000	2250
NOTE: All Manual Stackers can be customized as per requirements
